Product Highlights

Engineered for precision, safety, and durability, our high-voltage capacitor is a cornerstone for efficient power management in both three-phase and single-phase systems. It delivers unmatched reliability in demanding high-voltage environments.

Structural & Technical Advantages

• Durable Construction: Crafted with a seam-welded steel casing and integrated bushing insulators, ensuring robust mechanical strength and superior electrical insulation.
• Smart Core Design: Composed of capacitor elements (aluminum foil paired with film medium) interconnected in series or parallel, adapting to diverse voltage and capacitance requirements.
• Self-Protection Mechanism: Equipped with internal fuses that isolate faulty elements, allowing the capacitor to remain operational even during partial component failures.
• Safety-Centric Features: Three-phase models rated at 6kV and 10kV include discharge resistors for rapid and safe energy discharge, minimizing operational risks.

Key Specifications

• Environmental Adaptability: Operates within a temperature range of -25℃ to +50℃ and at altitudes ≤ 1,000m. Special specifications are available for installations above 1,000m.
• Voltage Withstand Capacity: Can endure a power frequency AC test voltage of 2.15 times the rated voltage or a DC test voltage of 4.3 times the rated voltage, both for 10 seconds.
• Capacitance & Loss Performance: Maintains a capacitance tolerance of -5% to +10% relative to the rated value, with a loss tangent value (tgδ) of ≤ 0.0005 at 20℃ under rated power frequency voltage.

Model Flexibility

We offer a diverse range of models to suit your specific needs. Examples include variants like HRBAM-11/√3-50-2AF (11/√3 kV rated voltage, 50 kvar rated capacitance), HRBAM-11/√3-100-2AF, and HRBAM-12/√3-50-2AF. For a full list of specifications, reach out to us directly.
